Screen Rotation Rockchip RK3566 8GB RAM 4K Media Player Android 11 TV Box for Digital Signage

$67.00$91.00

Specifications:

  • Android 11 TV Box
  • Powerful Rockchip RK3566 CPU support 4K@60fps and 8K@24fps
  • RAM: 4GB/8GB DDR4
  • ROM: EMMC 32GB/64GB/128GB
  • Wireless Connection: 2.4G/5.8GHz 2T2R Dual WiFi with bluetooth 4.2 and Gigabit Ethernet
  • Screen Rotation in setting, support portrait and landscape display
  • Application: Digital Signage, 4K Media Player, IPTV, Game
  • Optional: RTC, Linux OS, Customize logo and firmware

Description

Screen Rotation Rockchip RK3566 8GB RAM 4K Media Player Android 11 TV Box for Digital Signage

Ranboda X88 Pro 20 Android 11.0 TV Box, built-in the latest Rockchip RK3566 Quad Core CPU,2.4G +5GHz 2T2R Dual WiFi and Bluetooth 4.2,supports 8K @25fps and 4K@60fps,supports screen rotation, suitable for vertical display too.Powerful 5G WiFi, ideal for digital signage and display.

x88 pro 20 tv box (1)
x88 pro 20 tv box (7)
x88 pro 20 tv box (2)
x88 pro 20 tv box (6)

Parameters:

Specifications
ChipsetRK3566 Quad-Core 64bit Cortex-A55 @1.8GHz
GPUMali-G52 2EE
FLASHEMMC  32G/64GB/128GB
SDRAM4G/8GB
USB1 Type-A  USB3.0,1 Type-A  USB2.0
LANEthernet:10/100M/1000M standard RJ-45
Wireless2.4G /5G dual-band Wifi 802.11 a/b/g/n/ac
BluetoothV4.2
SPDIF/IEC958Optical
Card readerMicro SD cards ,Maximum support 64G
DisplayPortHDMI
HDMIHDMI 2.0a for 4k@60Hz
Power Indicator (LED)Power ON :blue; Standby :Red
RemoteIR
Power SupplyINPUT: 100-240V 50/60HZ   OUTPUT:DC 5V/2A
Operating temperature﹣10℃ to 45℃
OSAndroid  11.0
Support Decoder formatH.265HEVC/MVC Main10 Profile [email protected] up to 4096×2304@60fps
H.264 AVC/MVC Main10 Profile yuv400/yuv420/yuv422/@L5.1 up to 4096×2304@60fps
VP9 Profile0/2 [email protected] up to 4096×2304@60fps
VP8 verision2,up to 1920×1088@60fps
VC1 MPEG-4 MPEG-2 MPEG-1 up to 1920×1088@60fps
Support Media formatAvi/Ts/Vob/Mkv/Mov/ISO/wmv/asf/flv/dat/mpg/mpeg
Support Music formatMP3/WMA/AAC/WAV/OGG/DDP/HD/FLAC/APE
Support Photo formatHD JPEG/BMP/GIF/PNG/TIFF
HDD file systemFAT16/FAT32/NTFS
Support SubtitleSRT/SMI/SUB/SSA/IDX+USB
High Definition video output4K (4096×2160 pixel )
OSD type of languagesEnglish/French/German/Spanish/Italian/ etc multilateral languages
Mouse/ KeyboardSupport mouse and keyboard via USB;Support 2.4GHz wireless mouse and keyboard via 2.4GHz USB dongle
Software Specifications
Network FunctionKODI 18.1 ,Neflix,Vudu,Skype chatting,Picasa,Flicker,Youtube,Facebook,Online movies,etc
Other featureFree Internet searching,thousands of android applications,many kinds of games,etc.
AccessoriesPower adaptor,HDMI cable,user manual ,remote
OptionSupport mouse and keyboard via USB;Support 2.4GHz wireless mouse and keyboard via 2.4GHz USB dongle

Additional information

Weight1 kg
Dimensions22 × 18 × 8 cm
RAM/ROM

4GB/32GB, 8GB/64GB, 8GB/128GB

Remote

IR Remote, BT Voice Remote
