Specifications:
A high performance pocket Mini PC Stick, built-in with intel Gemini Lake J4125 Quad Core Quad Thread CPU, supports 64bit Windows 10 and Linux systems. built-in Dual WiFi, added with 100M/1000M RJ45 LAN , satisfy the network demand at different environments, ideal for office, TV and advertising signage.
Parameters:
| Processor | CPU | Intel® Celeron N4000/N4100 /J4005/J4105/J4125 Processors | ||||
| BIOS | AMI Source Code | |||||
| Memory | On Board | LPDDR4 -2400MHz | ||||
| Max Size | 6GB | |||||
| Graphics | GPU | Intel® UHD Graphics 600 | ||||
| Graphics Engine | DirectX 12.0, OpenGL 4.3, OpenCL 2.0 | |||||
| HDMI | Max. 3840 x 2160 @60Hz | |||||
| Network | Controller #1 | Realtek 8111F Gigabit Ethernet | ||||
| I/O | USB | 2 x USB 3.0 | ||||
| Display Interface | 1x HDMI | |||||
| LAN | 1 x RJ45 | |||||
| JAHC Switch | 1 | |||||
| Storage | On Board | 128GB,eMMC | ||||
| JAHC Tech | WatchDog | Timer 0~255 Second Time Out Support | ||||
| Auto Power On | Power Activated Automatically Start | |||||
| RTC | Set Up Independently Every day, A Week as a Cycle | |||||
| Wake On Lan | Supported | |||||
| Operation System | Windows | Windows 10 (64 bit) | ||||
| Linux | Supported | |||||
| Power | Power Type | DC-In | ||||
| Power Adapter | 12V/2.5A | |||||
| Mechanical | Dimensions (W x D x H) | 130mm*50mm*19.5mm | ||||
| Construction | Plastic | |||||
| Color | Grey | |||||
| Environment | Environment | 0℃ ~ 40℃ ( 32 ℉ ~ 104 ℉ ) at 0.7m/s Air Flow | ||||
| Relative Humidity | 95% @ 40℃ (non-condensing) | |||||
| Weight | 1 kg |
|---|---|
| Dimensions | 22 × 18 × 8 cm |
| CPU | Intel N4000, J4125 |
| Memory | 4GB, 6GB DDR4 |
| Storage | 64GB, 128GB eMMC |
