| Basic parameters |
| System | SoC: Allwinner H313 |
| CPU: Quad-core ARM Cortex™-A53 |
| GPU: Mali-G31 |
| DRAM: DDR3 2GB |
| FLASH: EMMC 8GB |
| OS: Android Q(10.0) |
| Network | RJ45 Interface 10M/100M adaptive |
| Build in Wi-Fi 2.4GHz+5GHz |
| I/O |
| Video Output | HDMI2.0(4K60), AV |
| Network | RJ45, Buildin Wi-Fi antenna |
| Peripheral Interface | USB2.0x2 |
| Power Interface | DC 5V 2A |
| Other Interface | IR receiver, LED indicator |
| Media |
| Video | Decoder:
• H.265 [email protected] decoder up to 4K@60fps
• VP9 Profile 2 decoder up to 4K@30fps
• AVS2 JiZhun 10bit decoder up to 4K@30fps
• H.264 BP/MP/[email protected] decoder up to 4K@30fps
• Multi-format 1080p@60fps video playback formats, including H.264 BP/MP/HP, H.263 BP, VP8, MPEG-1 MP/HL, MPEG-2 MP/HL, MPEG-4 SP/ASP@L5, AVS+/AVS JiZhun, WMV9/VC1, etc |
Format:
MKV, TS, M2TS, MOV, MP4, RM, RMVB, AVI, MPG, MPEG, DAT, VOB, FLV etc. |
| Audio | Decoder:
MPEG 1/2/2.5, Audio Layer 1/2/3, WMA Version 4/4.1/7/8/9, WMA Pro, LPCM, PCM, Vorbis, Flac, ALAC, APE, AAC-LC/HEAAC/HE-AAC v2, Real Audio, AC-3/DD+/AC-4, MPEG-H |
Format:
MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, ALAC, MPEG, MP1, MP2, MPA etc. |
| Subtitle Format | SMI, SRT, SSA, ASS,SUB, SUB+IDX, ISO Navigation |
| Photo Format | HD JPEG/BMP/GIF/PNG/TIFF |
| Features |
| Network Streaming | HTML5, RTSP, HLS, Smooth streaming |
| Multi-screen interactive | Miracast, DLNA and Airplay |
| Local Media Playback | Video/Audio/Picture |
| TV APP | Stalker/Ministra/Xtream code/M3U(4K HDR10), Google Play(TV version), Google Voice Assistant, YouTube(4K), Netflix(TV Version), Disney+(TV Version up to 720P), HBO Max(TV Version) Android TV APP |
| External Storage | USB storage max to 2TB (FAT32/NTFS) |
| System Upgrading | Upgrading via USB disk or internet |
| Other parameters |
| Input Voltage | DC IN 5V/2A |
| Power Consumption | 8W Max |
| Operation Temperature | 0~40℃, Humidity<95% |
| Product Size | Size: 79*79*17MM |
| Proposed Accessory | Power adapter, User manual, HDMI cable, BT Voice RCU |
