Specifications:
Windows 11 Mini PC with intel N5105 CPU, supports 64bit Windows 11 and Linux systems. With Dual HDMI and VGA display interfaces, enable to connect with three screens and displays, ideal for office, advertising displays and digital signage.
Parameters:
| Appearance | |||
| Type | Features | Spec | Optional |
| Product | Device | MINI PC | |
| Special | MINI PC, Ad Terminal Box | Optional | |
| Device size | 128mm*128mm*51.5mm | ||
| Case Material | Plastic | ||
| Weight | Net Weight 386g，Gross Weight 757g | ||
| Hard configuration | |||
| Type | features | Description | Optional |
| CPU | Platform | Intel Jasper Lake N5100; N5105; N5095 | Optional |
| Speed | 1.1GHz ( N5100) ; 2.0GHz ( N5105、N5095)； | ||
| Max frquency | 2.8GHz ( N5100) ;2.9GHz( N5105、N5095) | ||
| power disspation | 6W (N5100)、10W( N5105)、15W（N5095) | ||
| Memory | Type | LPDDR4X Onboard | |
| Storage | 8GB ; Max 16GB | Optional | |
| Storage | EMMC | Yes | |
| SSD | M.2 2280 Sata（NGFF/NVME customized），Max 2TB | Optional | |
| 2.5 ”HDD/SSD | support,Max to 2TB | Optional | |
| TF card | Not supported by default | ||
| RTC | BIOS support | Real-time clock,timing boot | |
| Auto power on | BIOS support | Yes | |
| TPM | CPU interation | supportTPM 2.0 | |
| Dual display | Video output | support HD+VGA dual display | |
| LED | status indicator | Blue light – Swith on | |
| Network | |||
| Type | Features | Description | Optional |
| WIFI | Type | intel 7265/ 3165/ RTL8821CE On Board | Optional |
| Agreement | IEEE 802.11 a, b/g, n, ac | ||
| BT | Type | intel 7265/ 3165/ RTL8821CE On Board | Optional |
| Agreement | Support BT 4.2 | ||
| 3G | build-in | No | |
| 4G | build-in | No | |
| Ethernet | LAN1 | 10M/100M/1000M Self-adaption | |
| Ports | |||
| Type | Features | Description | Optional |
| USB | USB2.0 | USB2.0 Type-A*2 | |
| USB | USB3.0 | USB3.0 Type-A*2 | |
| TF | expand external memory | No | |
| HD | Audio/Video output | HD 1.4b Type A x2 | |
| VGA | Video output | No | |
| RJ45 | Gbe | RJ45 x1 | |
| type_c | data transfer | No | |
| POWER | power | x1 | |
| DC IN | DC IN | 5.5/2.1mm DC Jack x1 | |
| Audio-in/out | Audio-in/out | 3.5mm Phone Jack x1 （Two-in-one interface） | |
| Antenna1 | FPC | WiFi 2.4+BT x1 | |
| Antenna2 | FPC | WIFI 5.0 | |
| Software configuration | |||
| Type | Features | Description | Optional |
| OS | OS version | Win11 Home/Win11 pro/Win11 IOT/ Ubuntu | |
| Applied environment | |||
| Type | Features | Description | Optional |
| Environment | operating temperature | 0~40℃ | |
| storage temperature | -20~60℃ | ||
| humidity | 90% @ 40 °C (without condensation) | ||
| Accessories | |||
| Type | Features | Description | Optional |
| Adapter | Plug type | input100~240V 50/60Hz,output 12V/2.5A , 12V/4A(N5095) DC 5.5*2.1mm | |
| IR remote control | No | ||
| VESA | Yes | ||
| Weight | 1 kg |
|---|---|
| Dimensions | 22 × 18 × 8 cm |
| CPU | Intel N5105 |
| Memory | 8GB, 16GB DDR4 |
| Storage | 128GB, 256GB, 512GB SSD |
